Product Name: Fire gate valve

1.Product Parameter

Product NameMaterial
Valve BodyDuctile iron, Epoxy spray painting
Wedge DiscDuctile iron, overall EPDM coating
Stem2Gr13, 45#chrome-plated steel, SS304, SS316, SS410 Stem
Hand wheelCast iron or iron sheet
Wedge NutSteel or Brass
working pressurePN10, PN16
testing pressureshell: 1.5 times rated pressure

seat: 1.1 times rated pressure

working temperature-10 °C to 80°C (NBR)

-10 °C to 120°C (EPDM)

suitable mediawater, oil and gas
Design StandardEN 593 , MSS SP67   API 609  BS5155
Inspection & TestAPI 598  ISO 5208  EN 12266
End StandardANSI B16.1 CL. 125LB & B16.5 CL. 150LB

AS 2129 Table D & E   BS 10 Table D & E

DIN 2501 PN6, PN10 & PN16

EN 1092 PN6, PN10 & PN16

ISO 2531 PN6, PN10 & PN16

ISO 7005 PN6, PN10 & PN16

KS B 1511 / JIS B 2210 5K & 10K

MSS SP44 CL. 150LB  AWWAC207

SABS 1123 Table 1000/3 & Table 1600/3

Face to FaceISO 5752 , EN 558 , MSS SP67 and API 609  DIN3202
Top FlangeISO 5211
